Battery flush valve for 1-1/2″ top spud WATER CLOSET with H2Optics® SENSOR ON VALVE – maximum 11-1/2″ height (c/l of inlet to base of outlet)
<!–
- Dimensions:
–>
<!–
- Origin:
–>
<!–
- Finish:
–>
- Chloramine resistant diaphragm
- Supplied with an advanced infrared sensor activated flush system that uses precise user distance measurements along with a bowl length setting to activate the correct flush for each usage
- Polished chrome plated body
- Electronic operated non-hold-open metal override button with 5 second lockout
- Scratch resistant replaceable lens window
- External water conserving flush adjustment: Factory set to 6 Litre(1.6 Gal.) – Field Adjustable from 4.2L to 25L (1.1 to 6.6 Gal.)
- 1″ FIP/Copper sweat inlet adaptor, angle check stop with protecting cap
- Adjustable 121mm (4-3/4″) plus or minus 11mm (7/16″) inlet/valve outlet centers
- Cover tube, stainless steel wall flange, spud flange, concealed spud nut, and 292mm (11-1/2″) outlet tube.
- ADA compliant, automatic operation battery powered infrared sensor
- Four (4) size AA alkaline batteries factory installed with valve in sleep mode for easy installation
- Quiet action, TECK® exposed diaphragm flush valve
- Right or left-hand supply installation
- 6 VDC input, 6 second arming delay
- Renewable seat
- Polished chrome plated vandal resistant metal cover with top mounted sensor operated H2Optics® electronics
- Hinged battery housing for easy maintenance
- Vacuum breaker
- Forged brass diaphragm retainer
- Set-up sensor range adjustment indicator lights
- Optional 24 hour automatic flush factory set to off
- Low battery flashing light (5000 flushes remaining) with battery strength indicator
- For 1-1/2″ spud water closet fixture
- Adjustable flow
- Battery operated, batteries included
- Hands-free operation
- Body mounted sensor
- 1″ inlet
- Manufacturer supplied links
- Manufacturer Web Site
- Installation Manual
- Brochure
- Parts Breakdown
- Specification Sheet
